The Macrolite CRASH is a compact, multi-function lighting effect designed to generate intense and dynamic visuals for stages, clubs, events, and audiovisual productions. Its main strength lies in the combination of kaleidoscope, patterns, laser, and strobe in a single unit, achieving complex effects without the need for multiple fixtures.
Equipped with high-intensity monochrome LEDs, the CRASH delivers defined beams and vibrant colors, accompanied by infinitely rotating kaleidoscopic effects and dynamic patterns that bring constant movement to the scene. This is complemented by a red, green, and blue laser system, along with high-brightness strobes, creating visual layers that enrich any show.
The unit can operate autonomously in automatic mode or be sound-controlled, synchronized in master/slave configurations, or integrated into professional systems via DMX512, providing precise control over colors, rotations, effect speed, strobes, and lasers. Its interface with LED display and control buttons facilitates quick and intuitive setup, even in high-traffic environments.
Versatile, powerful and easy to integrate, the Macrolite CRASH is an ideal solution for those looking for a striking visual effect in a compact format, perfect for both fixed installations and mobile mounts.
Technical Specifications
Equipment Type:
• Kaleidoscopic LED Effect with Patterns, Laser, and Strobe
Light source:
• 8 x 3W monochrome LEDs
• 2 x 5W yellow strobes
• 100mW red laser
• 3 x 50mW green lasers
• 80mW blue laser
Total power:
• 40 W
Dimmer:
• Electronic 0–100%
Strobe:
• 1–20 flashes per second
Effects:
• Infinitely rotating kaleidoscope
• Dynamic patterns
• RGB laser
• Built-in strobe
• Combined automatic programs
Operating Modes:
• DMX512
• Automatic
• Sound Control
• Master/Slave
DMX Channels:
• 9 channels
Controls:
• LED display with menu system
• Navigation buttons
Connectivity:
• DMX 3-pin XLR (input/output)
Power Supply:
• 110–220 V AC / 50–60 Hz
Power consumption:
• 40 W
Power cable:
• IEC – 1.2 m long
Installation:
• Truss or flat surface mounting
• Includes hanger bracket
