The BEAM 14R Ring is a high-power moving head projector designed for high-level performances, offering precise projection, vibrant colors, and advanced visual effects. Equipped with a 295W lamp, this model guarantees bright, stable, and long-lasting performance, ideal for stages, clubs, concerts, and live productions.
Technical Specifications:
- Power supply: AC110-240V, 50/60Hz
- Power consumption: 500W with triple protection system
- Average lifespan: 1500-2000 hours
- Cooling system: High-efficiency all-ball fan with triple protection
Optical and Effects Characteristics:
- High-speed dual strobe: 1-15 flashes per second
- Strobe modes: Random, pulsed, traditional
- Atomization: 0-100% with soft color effect
- Focus: Precise linear adjustment
- Dimming: 1-100% linear
- Multi-coated optical lens: 6 layers with anti-reflective coating
- Exit aperture: 145 mm
- Beam angle: 0° to 3.2° parallel beam
Colors and Gobos:
- Color Disc: 14 colors + white with rainbow effect and mid-color change
- Fixed Gobo Disc: 13 patterns with bidirectional rotation
- Prism:
16-sided prism
Combined 8+16+24-sided honeycomb prism
Double overlapping prism for spectacular effects
Control and Movement:
- Operating Modes: DMX512 (16 channels), Master/Slave
- Horizontal Scanning: 540° with 160-bit accuracy and electronic correction
- Vertical Scanning: 250° with the same accuracy and correction
- Display: Color display
- Motors: 12 ultra-quiet motors
Dimensions and Construction:
- Material: Molded alloy + high-temperature resistant plastic
- Product dimensions:
Base: 31 cm
Total height: 50 cm
Headboard diameter: 23.5 cm
- Package dimensions: 52 x 39 x 42 cm
- Electronic rectifier: Lighter, brighter, more stable, and more environmentally friendly
